Features
bullet35MM Stainless Steel Element
bulletHigh Sound Output
bulletExtremely Durable
bulletHigh Temperature Nylon 8/Noryl Housing
bulletPC Pins



Model Rated
Voltage
(VDC)
4.1KHz
Sq. Wave
Max.
Input
Voltage
 (VDC)
Max.
Current
Drain
at Rated
Voltage
 (mA)
Res.
Freq.
(KHz)
±0.5
Min. SPL
@ Rated
Voltage
(dBA/10cm)
PT-16A  9Vp-p 15Vp-p 20 3.4 100
PT-16B  9Vp-p 15Vp-p 20 3.4 105

Specifications and dimensions subject to change without notice.
