Home > Buzzers, Alarms & Sirens > Magnetic Transducers > MT-2512

Features
bulletSurface Mount, Infrared Reflow Solder
bulletSmall Size
bulletLightweight
bullet6V or 12VDC
bullet730, 740 or 1500\3200 Hz Resonant Frequency

Model Rated
Voltage
(VDC)
Operating
Voltage
 (Vp-p)
Current
Drain
at Rated
Voltage
 (mA)*
Res.
Freq.
(KHz)
±0.5
Min. SPL
@ Rated
Voltage
(dBA/10cm)
*
Coil
Resistance
(ohms)
Storage
Temp.
 Range
(deg. C)
Operating
Temp.
 Range
(deg. C)
Weight
(gm.)
MT-2512-01  6Vp-p 3 - 7 80 730 85 27 -30 - +85 -25 - +70 10
MT-2512-02  6Vp-p 3 - 7 70 1500 85 36 -30 - +85 -25 - +70 10
MT-2512-03 12Vp-p 8 - 14 55 1500 85 120 -30 - +85 -25 - +70 10
MT-2512-04  12Vp-p 8 - 16 55 740 85 120 -40 - +95 -40 - +95 10
*Value obtained applying rated voltage, resonant frequency, ½ duty square wave
Specifications and dimensions subject to change without notice.
