Features
bulletSurface Mount, Infrared Reflow Solder
bulletSmall Size
bulletLightweight
bullet1.5V or 3VDC
bullet3200 Hz Resonant Frequency

Model Rated
Voltage
(VDC)
Operating
Voltage
 (Vp-p)
Current
Drain
at Rated
Voltage
 (mA)*
Res.
Freq.
(KHz)
±0.5
Min. SPL
@ Rated
Voltage
(dBA/10cm)
*
Coil
Resistance
(ohms)
Storage
Temp.
 Range
(deg. C)
Operating
Temp.
 Range
(deg. C)
Weight
(gm.)
MT-1411-01  1.5Vp-p 1.2 - 1.7 80 3.2 85 9 -55 - +88 -10 - +55 1
MT-1411-02  3Vp-p 2 - 4.5 70 3.2 87 19 -55 - +88 -10 - +55 1
*Value obtained applying rated voltage, resonant frequency, ½ duty square wave
Specifications and dimensions subject to change without notice.
