Features
bulletSurface Mount, Infrared Reflow Solder
bulletSmall Size
bulletLightweight
bullet1.5V, 5, 6V or 12VDC
bullet2300 or 2400 Hz Resonant Frequency

Model Rated
Voltage
(VDC)
Operating
Voltage
 (Vp-p)
Current
Drain
at Rated
Voltage
 (mA)*
Res.
Freq.
(KHz)
±0.5
Min. SPL
@ Rated
Voltage
(dBA/10cm)
*
Coil
Resistance
(ohms)
Storage
Temp.
 Range
(deg. C)
Operating
Temp.
 Range
(deg. C)
Weight
(gm.)
MT-1310-01  1.5Vp-p 1 - 3 70 2.4 85 15 -40 - +90 -40 - +85 2
MT-1310-02  6Vp-p 4 - 8 40 2.4 90 47 -40 - +90 -40 - +85 2
MT-1310-03 12Vp-p 8 - 16 40 2.4 90 140 -40 - +90 -40 - +85 2
MT-1310-04  1.5Vp-p 1.4 - 3 20 2.4 75 15 -30 - +80 -20 - +70 2
MT-1310-05  5Vp-p 4 - 7 30 2.4 85 47 -30 - +80 -20 - +70 2
MT-1310-06  12Vp-p 8 - 15 30 2.4 85 140 -30 - +80 -20 - +70 2
*Value obtained applying rated voltage, resonant frequency, ½ duty square wave
Specifications and dimensions subject to change without notice.
