Features
bulletSmall Size
bulletLightweight
bullet1.5V, 6V or 12VDC
bullet2400 Hz Resonant Frequency

Model Rated
Voltage
(VDC)
Operating
Voltage
 (Vp-p)
Current
Drain
at Rated
Voltage
 (mA)*
Res.
Freq.
(KHz)
±0.5
Min. SPL
@ Rated
Voltage
(dBA/10cm)
*
Coil
Resistance
(ohms)
Storage
Temp.
 Range
(deg. C)
Operating
Temp.
 Range
(deg. C)
Weight
(gm.)
MT-1209-01  1.5Vp-p 1 - 2 75 2.4 75 6.5  -30 - +85 -25 - +70 2
MT-1209-02  6Vp-p 4 - 8 40 2.4 85 45  -30 - +85 -25 - +70 2
MT-1209-03  12Vp-p 7-16 40 2.4 85 140  -30 - +85 -25 - +70 2
*Value obtained applying rated voltage, resonant frequency, ½ duty square wave
Specifications and dimensions subject to change without notice.
