Features
bullet12 VDC
bullet3.6KHz Resonant Frequency
bullet Loud Output
bulletLow Current
bulletPCB Mount
Model Oper.
Voltage Range
(VDC)
Rated
Voltage
(VDC)
Max. Current
at Rated
Voltage (mA)
Res.
Freq.
(KHz)±
0.5
Min. SPL
@ Rated
Voltage (dBA/
30cm)
Pulse
Rate
@ Rated Voltage
(Pulses/
Second)
Tone Terminal
PB-199S12 3 - 20 12 10 3.6  90 NA Single Pins
Specifications and dimensions subject to change without notice.
