Home > Buzzers, Alarms & Sirens > Piezo Buzzers > PB-130




Features
bulletDual Tones
bullet12 VDC
bullet3-3.2KHz Resonant Frequency
bullet Loud Output
bulletAdjustable Sound Output
(Integrated Baffle)
bulletScrew mount with Leadwires
Model Oper.
Voltage Range
(VDC)		 Rated
Voltage
(VDC)		 Max. Current
@ Rated
Voltage (mA)		 Res.
Freq.
(KHz)±
0.5		 Min. SPL
@ Rated
Voltage (dBA/30cm)		 Pulse
Rate @
Rated Voltage
(Pulses/
Second)		 Tone Terminal
PB-130S12 6-16 12 65 3.0-3.2  105 NA Siren Leads
Specifications and dimensions subject to change without notice.
