Features
bulletSolid,  Pulse or Siren Tones
bullet12 or 24VDC
bullet2.9KHz Resonant Frequency
bulletLoud Output
bulletFlame Retardant Plastic Housing
bulletUL Approval Pending
bulletSingle Screw with Leads
or 3 Pin PCB Mounting



Model Oper.
Voltage
 Range
(VDC)
Rated
Voltage
(VDC)
Max.
Current
at Rated
Voltage
(mA)
Res.
Freq.
(KHz)
± 0.5
Min. SPL
@ Rated
Voltage
(dBA/
30cm)
Pulse
 Rate
@ Rated
Voltage
(Pulses/
Second)
Tone Terminal
PB-128S12 1 - 13 12 35 2.9  105 NA Solid Leads/
Pins

PB-128S24
1 - 28 24 20 2.9  100 NA Solid Leads/
Pins
PB-128P12 1 - 13 12 20 2.9  100 2/7 Pulse Leads/
Pins
PB-128D24 1-13 12 35/20 2.9  105/
100
2/7 Solid/
Pulse
3 Leads

PB-128S12 9-15 12 35 3.2 100 NA Siren Leads
Specifications and dimensions subject to change without notice.
