Features
bulletSolid or Pulse Tones
bullet110 or 240VAC
bullet2.9KHz Resonant Frequency
bulletMedium Output
bulletPanel Mount With Integrated Front Nut
bulletSealed Bottom (Plastic Plate with Resin Coating)
bulletAccepts Screw Lugs  or .25" Fast-On Lugs
bulletPCB Mounting Option
Model Oper.
Voltage
Range
(VAC)		 Rated
Voltage
(VAC)		 Max.
Current
at Rated
Voltage
(mA)		 Freq.
(KHz) ±
0.5 		 Min. SPL
@ Rated
Voltage
(dBA/
30cm)		 Pulse
Rate
@ Rated
Voltage
(Pulses/
Second)		 Tone Terminal
PB-121S110 30 - 120 110 20 2.9  90 NA Solid Screw
PB-121S240 60-250 240 20 2.9  90 NA Solid Screw
PB-121P110 30-120 110 10 2.9  80 0.8 - 1.2 Pulse Screw
PB-121P240 60-250 240 10 2.9  80 0.8 - 1.2 Pulse Screw
Specifications and dimensions subject to change without notice.
