Features
bullet12 or 24VDC
bulletLow Current
bullet2.4 - 3.4KHz Resonant Frequency
bullet Medium Output
bulletScrew Mount with Plate
Model Oper.
Voltage Range
(VDC)		 Rated
Voltage
(VDC)		 Max. Current
at Rated
Voltage (mA)		 Res.
Freq.
(KHz)±
0.5		 Min. SPL
@ Rated
Voltage (dBA/
30cm)		 Pulse
Rate
@ Rated Voltage
(Pulses/
Second)		 Tone Terminal
PB-108S12 1 - 18 12 16 2.4-3.4 80 NA Single Plate
PB-108S24 1 - 28 24 15 2.4-3.4 85 NA Single Plate
Specifications and dimensions subject to change without notice.
