Home > Buzzers, Alarms & Sirens > Piezo Buzzers > PB-105

Features
bullet12 VDC
bullet2.8KHz Resonant Frequency
bulletLoud Output
bulletPCB Mount
Model Oper.
Voltage Range
(VDC)
Rated
Voltage
(VDC)
Max. Current
at Rated
Voltage (mA)
Res.
Freq.
(KHz)±
0.5
Min. SPL
@ Rated
Voltage (dBA/
30cm)
Pulse
 Rate
@ Rated Voltage
(Pulses/
Second)
Tone Terminal
PB-105S12 3-28 12 8 2.8  90 NA Single Pins
Specifications and dimensions subject to change without notice.
