Features
bulletMulti-tone
bulletMedium to Loud Output
bullet12VDC or 24VDC
bullet3.2KHz/3.5KHz Frequency
bulletScrew Mount with Lead Wire
bulletPanel Mount (Front Nut)
Model Oper.
Voltage Range
(VDC)		 Rated
Voltage
(VDC)		 Max. Current
at Rated
Voltage (mA)		 Res.
Freq.
(KHz)
± 0.5		 Min. SPL
@ Rated
Voltage (dBA/
30cm)		 Pulse Rate
@ Rated Voltage
(Pulses/
Second)		 Tone Terminal
PB-103S12 1.5 - 16  12 15 3.5  95 NA Solid Leadwires
PB-103S24 1.5-28 24 20 3.5  95 NA Solid Leadwires
PB-103P12 3-15 12 10 3.2 90 2/7 Pulse Leadwires
PB-103D12 3-15 12 20 3.2 95/90 2/7 Solid/
Pulse		 Leadwires
Specifications and dimensions subject to change without notice.
