Features
bulletVDC: 12, 24V
bulletVAC: 12, 120, 240V
bulletMulti-tone
bulletLoud output
bulletScrew Mounting
with Lead Wire or PCB Pins
Model Oper.
Voltage
Range
(VDC or VAC)
Rated
Voltage
(VDC or VAC)
Max.
Current
at Rated
Voltage
(mA)
Res.
Freq.
(KHz)
±0.5
Min. SPL
Pressure
@ Rated
Voltage
 (dBA/
30cm)
Tone Terminal

DC Models

PB-101S12 9 - 15 12 40 2.9  105 Solid Wires/Pins
PB-101T12 9 - 15 12 40 2.6  105  Solid/
Pulse
 3 Wires/
3 Pins
PB-101T24 20-28 24 50 2.6  105  Solid/
Pulse
  3 Wires/
3 Pins
PB-101D12 6-15 12 80 2.6  105 Solid/
Pulse/
Siren
 3 Wires/
3 Pins

AC Models - Available Single or Pulse Tone

Operating Temperature Range: -20șC to + 80șC

PB-101AC-S12 3-24 12 8 2.9  90 Solid Wires/Pins
PB-101AC-S120 30-130  120 10 2.9  90 Solid Wires/Pins
PB-101AC-S240 60-250  240 10 2.9  90 Solid Wires/Pins

AC High Temperature Models - Available Single or Pulse Tone

Operating Temperature Range: -30șC to + 110șC

PB-101ACHT-S12 3-24 12 8 2.9  90 Solid Wires/Pins
PB-101ACHT-S120 30-130  120 10 2.9  90 Solid Wires/Pins
PB-101ACHT-S240 60-250  240 10 2.9  90 Solid Wires/Pins
Specifications and dimensions subject to change without notice.
