Features
bullet1.5 - 24VDC
bulletModerate Sound Output
bulletScrew Mounting with
Lead Wire or PCB Pins
Model Oper.
Voltage
Range
(VDC)		 Rated
Voltage
(VDC)		 Max.
Current
at Rated
Voltage
(mA)		 Res.
Freq.
(KHz)
±0.2		 Min. SPL
@ Rated
Voltage
 (dBA/
30cm)		 Pulse Rate
@ Rated
 Voltage
(Pulses/
Second)		 Tone Terminal
MB-21S1 1 - 3 1.5 25 2.8 80 NA Solid Pins/Leadwires
MB-21S3 2 - 5 3.0 35 2.8 85 NA Solid Pins/Leadwires
MB-21S6 4 - 9 6.0 35 2.8 85 NA Solid Pins/Leadwires
MB-21S9 6 - 11 9.0 40 2.8 85 NA Solid Pins/Leadwires
MB-21S12A 4 - 15 12 15 2.8 85 NA Solid Pins/Leadwires
MB-21S12B 9 - 15 12 40 2.8 90 NA Solid Pins/Leadwires
MB-21S24 15 - 28 24 20 2.8 90 NA Solid Pins/Leadwires
Specifications and dimensions subject to change without notice.
