Features
bullet3 - 24VDC
bulletSmall Size
bulletScrew Mounting with
Lead Wire or Solder Tabs
Model Oper.
Voltage
Range
(VDC)		 Rated
Voltage
(VDC)		 Max.
Current
at Rated
Voltage
(mA)		 Res.
Freq.
(KHz)
±0.5		 Min.
Sound
Pressure
@ Rated
Voltage
 (dBA/
30cm)		 Pulse
Rate
@ Rated
 Voltage
(Pulses/
Second)		 Tone Terminal
MB-12S3 2.0 - 4.0 3.0 30 400 85 NA Solid Pins/
Solder Tabs
MB-12S6 4.0 - 8.0 6.0 30 400 85 NA Solid Pins/
Solder Tabs
MB-12S12 8.0 - 16 12 30 400 85 NA Solid Pins/
Solder Tabs
MB-12S24 16 - 28 24 30 400 85 NA Solid Pins/
Solder Tabs
Specifications and dimensions subject to change without notice.
